Toyota Obd Codes
12 - Crankshaft Position Sensor (P0335)
13 - Crankshaft Position Sensor (P0335, P1335)
14 - Ignition system, coil No. 1 (P1300) and No. 4 (P1315)
15 - Ignition system, coil No. 2 (P1305) and No. 3 (P1310)
16 - Automatic transmission control system
18 - VVT-i system - phases (P1346)
19 - Accelerator pedal position sensor (P1120)
19 - Accelerator pedal position sensor (P1121)
Toyota Diagnostic Fault Codes List. See also: Toyota PDF Service Manuals. P0100 Air Flow Sensor Circuit Malfunction. P0101 Flow sensor signal output from the permissible range. P0102 Air Flow Sensor Low Output Level. P0103 High flow sensor output. P0105 Air Pressure Sensor Fault. P0106 Air pressure sensor signal output from the. OBD II Diagnostic Trouble Codes Page 2 Created by Oemy's UltraPower Performance Introduction The diagnostic trouble codes listed are the most likely definition; some manufactures have specific codes for individual models. If the trouble code listed does not apply to your vehicle consult your engine or chassis builder. PO100 - PO199 Numbered Code. Toyota OBD/OBD2 Codes 96 & later are OBD2 systems and require a scantool Note: We are finding that some 94 & 95 Toyota vehicles are OBD2 compliant and require a scan tool. Check your emissions decal under the hood to confirm if you have an OBD2 compliant vehicle.
21 - Oxygen sensor (P0135)
22 - Coolant temperature sensor (P0115)
24 - Intake air temperature sensor (P0110)
25 - Oxygen sensor - poor mix signal (P0171)
27 - Oxygen sensor # 2
31 - Absolute pressure sensor (P0105, P0106)
34 - Turbocharger system
35 - Turbocharger pressure sensor
36 - CPS sensor (P1105)
39 - VVT-i system (P1656)
41 - Throttle Position Sensor (P0120, P0121)
42 - Vehicle speed sensor (P0500)
43 - Starter signal
47 - Additional throttle position sensor
49 - Fuel pressure sensor (D-4) (P0190, P0191)
51 - Status of switches
52 - Knock sensor (P0325)
53 - Detonation signal
Toyota Obd Code 21
55 - Knock Sensor No.2
Toyota Obd Code 14
58 - Drive SCV (D-4) (P1415, P1416, P1653)
59 - Signal VVT-i (P1349)
71 - EGR system (P0401, P0403)
78 - injection pump (D-4)
89 - Drive ETCS (P1125, P1126, P1127, P1128, P1129, P1633)
92 - Cold start nozzle (D-4) (P1210)
97 - Nozzles (D-4) (P1215)
98 - The vacuum gauge in the vacuum amplifier of brakes (C1200)
